10-1357-10
EAN: 5904405958568
Profile LUMINES type atom Sky blue lacquered 1 m
Please contact your local distributor
| Stock status: | average |
| Purpose | Furniture |
| Type of assembly | surface |
| Profile length | 1m |
| Color | Sky Blue (RAL 220 70 10) |
| System | atom |
Color
White (lacquered)
Black (anodized)
Black (lacquered)
Light Ivory (RAL 1015)
Sky Blue (RAL 220 70 10)
Reed Green (RAL 6013)
Rock Anthracite (RAL 7016)
Silver (anodized)
Raw
Available variants:
Purpose
Type of assembly
Profile length
System
Responsible entity: LED Labs S.A., ul. Zakopiańska 2C, 30-418 Kraków, Polska | Contact: info@led-labs.pl
Product sold only as a complete set
Product description
Surface or suspended LED profile designed for backlighting decorative and accent in furniture and finishing interiors.
Color varieties:
- silver anodized,
- black anodized,
- black lacquered,
- white lacquered,
- raw,
- Rock Anthracite | RAL 7017,
- Reed Green | RAL 6013,
- Sky Blue | RAL 220 70 10,
- Light Ivory | RAL 1015
Installation method:
- surface
- suspended
Cover:
NANO
*OPAL
*CLEAR
*BLACK
End caps:
- Plugs with marked hole (plastic): silver, black, white, grey, Rock Anthracite RAL 7016, Reed Green RAL 6013, Sky Blue RAL 220 70 10, Light Ivory RAL 1015
- End caps without hole (anodized aluminum): silver, black
- Hole plugs (anodized aluminum): silver, black
- End caps without hole (painted aluminum): black, white, Rock Anthracite RAL 7016, Reed Green RAL 6013, Sky Blue RAL 220 70 10, Light Ivory RAL 1015
- Hole plugs (painted aluminium): black, white, Rock Anthracite RAL 7016, Reed Green RAL 6013, Sky Blue RAL 220 70 10, Light Ivory RAL 1015
Accessories:
- Atom mounting bracket
Profile sold in lengths: 1000 mm, 2020 mm, 3000 mm.
| Type of bending | Lighting direction (position of the cover in the fixture) | FLEX cover | PMMA/PC cover |
| horizontal (transverse) | down | — | — |
| vertical | inward | — | 150 |
| vertical | outward | — | 125 |
Minimum bending radius (mm) for the given cover. Max. circle diameter: 1850 mm (from a 6 m profile).
Tolerance: +/- 5%. Production end allowances: 250 mm. Bent profiles are available only in a lacquered finish.
Bending service available upon prior contact with customer service.
Installation instructions for the LED atom profile with a NANO cover using atom mounting bracket.
The end result of installing the LED atom profile with a NANO lampshade using atom mounting bracket.
