10-0181-10 EAN: 5902973362404

Lumines profile type Dileda lacquered white, 1 m

Your price: Please contact your local distributor
Stock status: average
Purpose Architectural
Type of assembly surface
Profile length 1m
Color White (lacquered)
System DILEDA

LUMINES "DILEDA" surface mounted profile








Color
Silver (anodized)
White (lacquered)
Black (lacquered)
Available variants:

Purpose

Type of assembly

Profile length

System

Product description

Profile DILEDA Lumines is surface profile designed for the construction of light with two LED strips.

Color versions:
- anodized silver,
- lacquered white (RAL9016),
- lacquered black (RAL9005 mat)

Mounting:
two-sided adhesive tape,
mounting screws,
pendants

Accessories for aluminum profile DILEDA Lumines

Diffuser (covers):
- diffuser DOUBLE PMMA - transparent, frozen, milky, milky frosted, black
  (mounted from push-up)
- LUMINES raster DOUBLE cover (silver)

PLUGS:
- aluminium caps with or without a hole in 3 color variations (white, silver, black),
- plastic caps with push-hole in 4 color variations (white, silver, gray, black)

OPTIONAL ACCESSORIES :
- non-contact switch,
- stand,
- joint female
- joint male,
- hinge
- slings,
- straight connector,
- the angle connector 90 °
- wishbone angled,
- the angle connector 120

Profile is available in standard lengths: 1000 mm, 2020 mm, 3000 mm.

Installation Instructions DILEDA profile with cover DOUBLE using (1) double-sided tape (2) of the mounting screw.

The end result DILEDA mounting profile with cover DOUBLE using (1) double-sided tape (2) of the mounting screw.









Joining profiles DILEDA by fasteners.





Installation profile DILEDA as a pendant lamp.

Scheme assembly elements of the lighting system using the profile DILEDA and (1) DOUBLE lens (2) of LED strips (3) without plug hole (3a) of the plug hole, and (4) of the mounting screw.
